- Bolt pattern8x165.1 · Same recorded PCD
- Center bore124.9 mm · same recorded hub figure
- Wheel geometryNot fully recorded
Wheel width/offset data is incomplete.
2012 Ford E-250 Wheel Interchange
OEM wheel and tire fitment specs for the 2012 Ford E-250, including bolt pattern (PCD), center bore diameter, thread size, rim diameter, rim width, wheel offset, and backspacing.
Recorded OEM specifications for the 2012 Ford E-250, donor years with overlapping ranges, and a calculator to compare a selected wheel. Range overlap is not a guaranteed fit.
2012 Ford E-250 Fitment Specs
Baseline mounting dimensions used for interchange decisions.
Bolt Pattern8x165.1
Center Bore124.9 mm
Lug ThreadM14 x 2.00 View M14 x 2.00 options on Amazon
OEM Wheel SizesNot fully verified in current dataset
OEM WidthsNot fully verified in current dataset
OEM Offset RangeNot fully verified in current dataset
Thread-only product links are shopping examples, not verified fits. Seat style is not confirmed here. As an Amazon Associate we earn from qualifying purchases.
Donor vehicles with overlapping OEM specs
These are vehicle-year records whose recorded OEM ranges overlap this 2012 Ford E-250. Overlap is not a guarantee that a specific wheel will install. Selected-wheel comparison is in the calculator below.
Evaluated 15 donor years. Listed 15 eligible overlaps (not all evaluated years are compatible). Showing all listed.
1999–2011, 2013–2014 Ford E-250
Insufficient dataInsufficient or mixed data
Ford E-250 Years With Compatible Wheels
Only years with evidence-based interchange relationships are listed. Adjacent years are not assumed compatible.
Will Wheels From Another Vehicle Fit?
Compare a donor vehicle or custom wheel against this 2012 Ford E-250. Use Compare in calculator on a donor row above to fill the donor side of this same calculator.
Compare
Compare wheel compatibility between two vehicles
Wheels from (donor vehicle)
Installed on (your vehicle)
Selected Car:
2012 Ford E-250
Compare Rims
Specification
Wheels from
Installed on
Result (Click it)
Bolt Pattern
The total number of bolt holes and the diameter of the circle they form.
-
8x165.1
Center Bore
The hole in the center of the wheel that fits over the vehicle’s hub.
-
124.9 mm
Thread Size
The size and spacing of the threads on the bolts or nuts that hold the wheel in place.
-
M14 x 2.00
Rim Diameter
The wheel diameter in inches that determines which tire sizes will fit.
-
-
Rim Width
The distance between the inner edges of the wheel is measured in inches.
-
-
Wheel Offset
How far the wheel sits inward or outward relative to the hub mounting surface.
-
-
Backspacing
Shows how much space the wheel takes up toward the inside of the vehicle.
-
-
Wheel Fasteners
The type of hardware used to secure the wheel to the vehicle.
-
-
Wheel Fitment Parts for the 2012 Ford E-250
Example products matched to recorded thread, hub, or spacer dimensions. They are not verified fits. Confirm seat style, thickness, and clearance before ordering.
Lug Nuts / Wheel Bolts
M14 x 2.00
Dorman 611-206 Wheel Lug Nut M14-2.0
M14 x 2.00 · Thread match only; seat style is not verified
View on Amazon →
McGard 64020 Chrome Cone Seat Style Lug Nuts (M14 x 2.0 Thread Size)
M14 x 2.00 · Thread match only; seat style is not verified
View on Amazon →
White Knight 3850XL-33AM Chrome M14 x 2.00 Spike Lug Nuts
M14 x 2.00 · Thread match only; seat style is not verified
View on Amazon →As an Amazon Associate we earn from qualifying purchases. Product availability and pricing may change.
2012 Ford E-250 Wheel Fitment
| Bolt Pattern | 8x165.1 |
|---|---|
| Center Bore | 124.9 mm |
| Thread Size | M14 x 2.00 |
| Rim Diameter | Not specified – check via calculator |
| Rim Width | Not specified – check via calculator |
| Wheel Offset | Not specified – check via calculator |
Use the calculator below to compare wheels from another vehicle against your 2012 Ford E-250, or check compatible donor vehicles that share the same bolt pattern and center bore.
Fitment Basics
- Always confirm center bore matches your hub, or use hub-centric rings to take up the gap.
- Check offset carefully – wheels that stick out too far can rub on fenders or suspension components.
- Verify thread size and lug type before buying replacement bolts or lug nuts.
- When in doubt, use the calculator below to compare exact specs side by side.
Methodology and sources
Wheel interchange depends on more than bolt pattern. Where data is available, this site compares recorded OEM values:
- Bolt pattern / PCD
- Center bore direction (donor wheel bore must not be smaller than the hub)
- Wheel diameter, width, and offset against known OEM ranges
- Lug thread / hardware differences (vehicle-side hardware)
A normal wheel spacer does not change bolt pattern. Hub rings cannot enlarge a wheel bore that is smaller than the hub. Brake clearance and tire package fitment still require vehicle-specific checks when not confirmed in the dataset.
